Leaf Chains consist of several applications and are regulated by ANSI. They are used for forklift masts, for low-speed pulling and tension linkage, and as balancers between head and counterweight in several machine gadgets. Leaf chains are at times even referred to as Balance Chains.
Features and Construction
Made of a simple pin construction and link plate, steel leaf chains is identified by a number that refers to the lacing of the links and the pitch. The chains have certain features such as high tensile strength for each section area, that allows the design of smaller machines. There are A- and B- kind chains in this particular series and both the AL6 and BL6 Series have the same pitch as RS60. Lastly, these chains cannot be driven with sprockets.
Handling and Selection
Comparably, in roller chains, all of the link plates have higher fatigue resistance because of the compressive stress of press fits, while in leaf chains, just two outer plates are press fit. The tensile strength of leaf chains is high and the most permissible tension is low. When handling leaf chains it is essential to check with the manufacturer's guidebook to be able to guarantee the safety factor is outlined and utilize safety measures always. It is a great idea to carry out utmost care and use extra safety guards in functions wherein the consequences of chain failure are serious.
Higher tensile strength is a direct correlation to the use of more plates. Because the utilization of a lot more plates does not enhance the most allowable tension directly, the number of plates could be limited. The chains require regular lubrication for the reason that the pins link directly on the plates, generating a really high bearing pressure. Utilizing a SAE 30 or 40 machine oil is normally advised for the majority of applications. If the chain is cycled more than one thousand times each day or if the chain speed is more than 30m for every minute, it would wear very quick, even with continual lubrication. Hence, in either of these conditions the use of RS Roller Chains would be more suitable.
AL type chains are only to be utilized under particular situations like for instance where there are no shock loads or when wear is not really a big problem. Be sure that the number of cycles does not exceed one hundred per day. The BL-type would be better suited under different conditions.
The stress load in components would become higher if a chain with a lower safety factor is chosen. If the chain is likewise used amongst corrosive situations, it can easily fatigue and break really fast. Doing frequent maintenance is really important if operating under these kinds of conditions.
The outer link or inner link type of end link on the chain will determine the shape of the clevis. Clevis connectors or also known as Clevis pins are made by manufacturers, but the user usually provides the clevis. An improperly made clevis could decrease the working life of the chain. The strands should be finished to length by the producer. Check the ANSI standard or contact the producer.
